Model
|
SL1604
|
SL1804
|
Type
|
4×4
|
overall dimension(mm)
|
5390×2696×3450
|
front track(mm)
|
1580-2176(1880)
|
rear track(mm)
|
1700-2395(1800)
|
Min. groud clearance(mm)
|
459
|
495
|
turning radius
|
one side brake(m)
|
5.0
|
no brake(m)
|
6.2
|
Min.operating weight(㎏)
|
7100
|
7350
|
Gear box
|
12F+4R
|
speed
|
forward(km/h)
|
2.25-29.06
|
2.35-30.69
|
backward (km/h)
|
4.25-11.47
|
4.44-11.99
|
Engine
|
Model
|
SC8D190.1G2
|
SC8D215G2
|
Type
|
Vertical, turbocharged, intercooled, direct-injection diesel engine
|
Rated power(kW)
|
118
|
132
|
Rated speed(r/min)
|
2200
|
Rated fuel consumption(g/kW.h)
|
≤235
|
Tire
|
front
|
14.9-28
|
16.9-28
|
rear
|
18.4-38
|
20.8-38
|
Max suspension force (kN)
|
≥36
|
|
|
PTO
|
540(6spline)/1000(20spline)
|
Max pto power(kw)
|
≥106
|
≥118.5
|
tilling depth control
|
up,down and floation
|
Max ballast front/rear(kg)
|
720/300
|
810/450
|
Max traction force (kN)
|
≥55.5
|
≥58.5
|
|
