Model |
SL950 |
Type |
2WD Wheeled Type |
Dimensions of Tractor(mm) |
Length (to front ballast) |
4530 |
Width |
2050 |
Height (to the exhaust vent) |
2810 |
Tread |
Front Wheel |
1485 |
Rear Wheel |
1608 |
Axle Base |
2200 |
Min.Ground Clearance |
430 |
Structure weight (kg) |
3010 |
Ballast weight
(kg) |
Front ballast |
250 |
Rear ballast |
170 , 340 (optional) |
Rated traction force (kg) |
1900 |
Engine |
Model |
LR4M5-23 |
Manufacturer name |
Yituo Engine factory |
Type |
Vertical,4-Cylinder,Water Cooled and 4-stroke |
Turbocharged / Natural aspirated |
Rated Power(kw) |
69.8 |
Rated speed (r/min) |
2300 |
Fuel |
Diesel |
Tyre |
Front Wheel |
6.50-20 |
Rear Wheel |
16.9-34 / 18.4-30 |
Clutch |
Dual-stage clutch |
Steering |
Power steering |
Transmission Type |
F8+R4 or F16+R8 shuttle |
Suspension Type |
3-point links |
PTO |
Type and Rev |
Semi-independent Type 540/1000 |
Spline Size |
F35 Rectangle Spline with 8 teeth |
